4. Fuel System
4-9
Air Cleaner
Removal/Installation
Remove air cleaner and rear inner fender
mounting screw.
Loosen connection hose clamp.
Remove 2 bolts and then remove the air
cleaner.
Install in the reverse order of removal
procedures.
1 screw
2 bolts
Hose clamp
