11. BODY COVER
11-5
Remove the 8 mounting screws between the
front cover and the front inner box.
Remove the front cover from the frame.
Installation
Install according to the reverse procedure
of removal.
FRONT INNER BOX
Removal
Remove the 8 mounting screws of front
cover from the inner box A.
Remove the hook screw bolt from the front
inner box.
1 bolt
Front cove
r
screws 4×2
screws 4×2
