Sym JET 4 R 50 Series User Manual

9. Final Driving Mechanism
9-1
Maintenance Information····················· 9-2
Troubleshooting··································· 9-2
Disassembly of Final Driving Mechanism
·······························································9-3
Inspection of Final Driving Mechanism
································································ 9-6
Bearing Replacement ··························· 9-7
Re-Assembly of Final Driving Mechanism
································································ 9-8
Bearing 6201
Bearing 6203
Bearing 6201
Bearing 6203
Oil seal 17x30x6
Bearing 6004UU
1.0~1.5kgf-m
2.4~3.0kgf-m
1.0~1.5kgf-m
Oil seal 27x42x7
