MECHANISM ILLUSTRATIONS
Fuse &C.D.I Battery
Headlight switch
/starter switch
Tail light
Fuel tank/oil cap
Storage box
Ignition switch
Rear brake level
Side stand
Frame number
Gear oil
filling bolt
Gear oil draining
bolt
Front turn
signal light
Front light/
Position light
High& Low beam/ Turn
signal/Horn switch
Air Cleaner
Kick starter
pedal
Main stand
Front brake level
Exhaust muffler
Rear turn
signal light
Engine number
