2. Service Maintenance Information
2-4
Fuel Filter
Remove the luggage box.
Remove the fuel line from the fuel filter.
Replace the fuel filter with new one.
Install the fuel filter. The arrow indicates the fuel
flowing direction.
Check the fuel line for leaking.
Engine Oil Line
Remove the body cover.
Check the engine oil line and replace damaged
parts.
Remove the filling pipe from the oil pump, and
drain oil into a cleaning container.
Loosen the clamp under the engine oil tank, and
then remove the oil pipe.
Bleed the air inside the oil pump and oil pipe if air
found.
Install the body cover.
Fuel filter
Oil filling pipe
Engine oil pipe
Oil pump
To Next Page
