Sym JET 4 R 50 Series - Electrical Equipment

SYM 16. ELECTRICAL EQUIPMENT
16-1
MECHANISM DIAGRAM ................... 16-1
PRECAUTIONS IN OPERATION ...... 16-2
TROUBLE DIAGNOSIS ..................... 16-4
CHARGING SYSTEM ........................ 16-5
IGNITION SYSTEM............................ 16-11
STARTING SYSTEM.......................... 16-14
METER ............................................... 16-15
LIGHTS/BULBS.................................. 16-17
SWITCH.............................................. 16-19
FUEL UNIT .........................................16-22
MECHANISM DIAGRAM
Spark Plug
AC. Generator
Fuse
Battery
IG. Coil
Fuel Unit
Main Switch
Reg. Rec. Comp
Horn
Resistor Comp
Winker Relay
CDI Unit
Oil Level Switch
Thermo Switch
Carburetor heater
