HEADLIGHT ADJUSTMENT
Remove the front cover.
Turn on the main switch.
Turn the headlight adjustment screw. And adjust
the headlight beam height.
Then, tighten the adjustment screw after the
beam height in proper position.
Caution
NUTS, BOLTS TIGHTENESS
Perform periodical maintenance in accord with
the Periodical Maintenance Schedule.
Check if all bolts and nuts on the frame are
tightened securely.
Check all fixing pins, snap rings, hose (pipe)
clamps, and wire holders for security.
y To adjust the headlight beam follows related
regulations.
y Improper headlight beam adjustment will
make in coming driver dazzled or insufficient
lighting.
Headlight adjustment screw
