16. Steering / Front Wheel / Front Cushion
16-8
Assembly
Assemble in reverse order of disassembly.
Apply a coat of grease on the inner side of the
dust-proofing oil seal.
Install the dust proofing oil seal and the left and
right bushes.
Installation
Insert the wheel axle through the front shock
absorber and wheel.
Tighten the nut for the wheel axle.
Torque value: 10.0 ~ 12.0 kgf-m
