5
. Fuel Injection System
5-21
Remove the fuel pump and fuel unit.
Caution
● Check if the oil seal is deformed or
damaged. Replace it with new one if
necessary.
Check if the fuel filter is contaminated or
clogged. Replace it with new one if necessary.
Installation
Install in the reverse order of
removal.
Caution
● Do not bend the fuel unit float arm
● Do not fill out too much fuel in the tank.
● Align the assembly mark when installing
the fuel pump.
Oil seal
Fuel filter
