3 - 6 Symbol LS9203/LS9203i Product Reference Guide
The signal descriptions in Table 3-3 apply to the connector on the scanner and are for reference only.
Table 3-3
Scanner Signal Pin-outs
Symbol LS9203/LS9203i
Pin RS-232 Keyboard Wedge Wand USB
1
Reserved Reserved Reserved Jump to Pin 6
2
Power Power Power Power
3
Ground Ground Ground Ground
4
TxD KeyClock DBP Reserved
5
RxD TermData CTS D +
6
RTS KeyData RTS Jump to Pin 1
7
CTS TermClock Reserved D -
8
Reserved Reserved Reserved Reserved
9
Reserved Reserved Reserved Reserved
10
Reserved Reserved Reserved Reserved
