Cables
Connecting the Cable to the Scanner
1. Power down all devices that will be connected to the scanner.
2. Plug the modular connector on the cable into the receptacle in the bottom of the
Phaser handle.
Figure 2-1. Connecting the Cable to the Phaser
The twist-lock
can be slipped
down the cable
to facilitate
connecting.
Power Supply
Lead
Cable Connector
on Host Side
