Symbol P460 - Pin-Outs; Cradle

4-7
Maintenance And Specifications
Pin-outs
Cradle
The following table shows the pin-outs for both COM1 and COM2 on the cradle.
Table 4-3. Cradle Pin-outs
Pin Cradle
1BREQ
2 VCC (out of cradle)
3Ground
4 Synapse Data
5 Synapse Clock
6 RXD (into cradle)
7 TXD (out of cradle)
8 BACK
9CTS
10 RTS
