XLi IEEE 1588 Clock 117
997-01510-03, Rev. C, 12/12/2006
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
• PTP CLOCK ID - GPS
Command Line
To obtain the status of the PTP card, send a command using the following format:
F130<SP>B<N><SEP>S
where:
For example, enter:
F130 B4 S
The XLi responds (example):
F130 B4:
PTP PART NUMBER 87-8036
SOFTWARE 230-01510-15v1.19
FPGA 230-01510-14v050
PTP PORT STATE: PTP LISTENING
SLAVE CLOCK SYNCHRONIZED: UNLOCKED
PTP UUID (MAC ADDR): 00:A0:69:01:2F:B5
PTP TECHNOLOGY: ETHERNET
PTP NUMBER OF PORTS: 1
PTP STRATUM: 255
PTP CLOCK ID: DFLT
If this option card is a PTP SLAVE, the following information will be provided:
SLAVE CLOCK SYNCHRONIZED: LOCKED<CR><LF> ( or UNLOCKED)
PTP UUID (MAC ADDR) : 00:A0:69:00:E3:F4<CR><LF>
PTP TECHNOLOGY: ETHERNET<CR><LF>
PTP NUMBER OF PORTS: 1<CR><LF>
PTP STRATUM: 2<CR>LF>
PTP CLOCK ID: GPS<CR><LF>
F
= ASCII character F.
130 = function number.
<SP> = ASCII space character one or more.
B = ASCII character to denote Option Bay number follows
<N> = Option Bay Number, 1 through 4.
<SEP> = A white space separator, such as a space or tab character
S = ASCII character for “Status Request”
<LT> = line terminator, either a carriage return and line feed for output strings or a
carriage return only for input strings.
