28 XLi IEEE 1588 Clock
997-01510-03, Rev. C, 12/12/2006
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
1
Keypad Examples
The following examples show how to use the keypad effectively.
To open a function using ENTER:
To open a function using MENU:
To change the settings in a function, and not save them:
Other ways to abandon new settings in a function:
Press Result
ENTER Displays the “FUNCTION” prompt
2 Enter the function’s number (“2” in this example)
ENTER Displays F2’s first screen, “
DISPLAY HOUR FORMAT: 24 HOUR
Press Result
MENU Displays F1 on the front panel display
UP/DOWN ARROW Scrolls through the list of functions
ENTER Opens the function and displays its first screen
Press Result
MENU Displays “F1: TIME ZONE OFFSET
ENTER Displays “
TIME ZONE OFFSET –08:00
UP ARROW Changes the minus sign in “
– 08:00” to a plus in “+08:00
RIGHT ARROW Moves the cursor to the right, under
0”.
UP ARROW Changes “
0” to “1”, making “+18:00
ENTER XLi asks “
SAVE CHANGES? YES
UP ARROW Changes “
YES” to “NO
ENTER Abandons the changes and displays the Status Display
Press Result
CLR Abandons all changes and displays to the first screen in the function
TIME Abandons all changes, exits the function, and displays the Time Display
STATUS Abandons all changes, exits the function, and displays the Status Display
