80 XLi IEEE 1588 Clock
997-01510-03, Rev. C, 12/12/2006
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
1
F100 – Network Port Configuration & XLi Firmware
F100 provides two groups of commands:
• Group 1, available through the keypad/display and the command line, provides access to
network port settings and hardware/Firmware status information.
• Group 2, available through the command line only, provides commands for changing system
firmware, changing SNMP parameters, changing the user name/password, resetting the unit,
and pinging other network devices.
Warning: The F100 commands have the capacity to remove the XLi from the network and disable the
XLi’s system firmware. Use judiciously.
Reboot Warning: Saving changes to any F100 parameter
using the keypad/display will reboot the XLi.
Some of the F100 command line commands also reboot the XLi. These are identified in the following
documentation.
Group 1
You can use both the keypad/display and the command line interface to access the following
parameters:
• Ethernet address: XLi contains a unique Ethernet or Media Access Control (MAC) address
comprised of a unique number assigned to the manufacturer, and a unique number assigned to
the unit. This is factory set and cannot be changed.
• IP Address: Sets a static Internet Protocol (IP) address for the unit.
• Subnet Mask: Sets a valid subnet-mask used in IP addressing. Subnetting allows for the more
efficient allocation of network addresses and management of network traffic.
• Default Gateway: The address of the router that handles packets addressed to IP devices
outside the local-area network.
• 10 100 BASE-T: The network port bandwidth setting, 10 Base-T or AUTO. (10 Base-T only for
earlier XLi hardware).
• Remote Lockout: Enables or disables remote access through the XLi’s standard network port.
Enabling Remote Lockout limits users to the front-panel keypad or Serial I/O port.
• Flash CRC: Status - Passed or failed.
• RAM: Status - Passed or failed.
• Serial: Status - Passed or failed.
• Version Test: Status - Passed or failed
