116 XLi IEEE 1588 Clock
997-01510-03, Rev. C, 12/12/2006
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
1
F130 - Precision Time Protocol Status
Note: The IEEE 1588 card becomes available in the user interface after the XLi IEEE 1588 Clock has
been operating for approximately 3 to 5 minutes.
Use F130 to obtain the following information about the IEEE 1588 card:
•Firmware Version
PTP card status
Keypad
To use F131, press the following keys on the front panel keypad:
ENTER 131 ENTER
Use the left/right arrow keys to position the cursor.
Use the up/down arrow keys to select an option or change a value.
Use the ENTER key to continue to the next screen. F130 is a status function and cannot be used to
change settings.
The following screens are available the keypad (shown with example values):
PTP AVAILABILITY - OPTION BAY 1
PTP PART NUMBER - 87-8036
SOFTWARE - 230-01520-15V1.3
FPGA - 230-01510-14v001
PTP PORT STATE - PTP MASTER (or one of the following:
- PTP INITIALIZING
- PTP FAULTY
- PTP DISABLED
- PTP LISTENING
- PTP PRE-MASTER
- PTP MASTER
- PTP PASSIVE
- PTP UNCALIBRATED
-PTP SLAVE
- UNKNOWN)
SLAVE CLOCK SYNCHRONIZED - LOCKED (or UNLOCKED)
PTP UUID (MAC ADDR) - 00:A0:69:00:E3:F4
PTP TECHNOLOGY - ETHERNET
PTP NO. OF PORTS - 1
PTP STRATUM - 2
