XLi IEEE 1588 Clock 91
997-01510-03, Rev. C, 12/12/2006
2
5
1
SSSSSSSSSSSS SSSSSSSSSS SSSSSSS S SSS S SSSSS S
SEC: 14 RE: 0
SEC: 15 RE: 0
SEC: 16 RE: 0
SEC: 17 RE: 0
SEC: 18 RE: 0
SEC: 19 RE: 0
SEC: 20 RE: 0
SEC: 21 RE: 0
SEC: 22 RE: 0
FLASH SUCCESSFULLY PROGRAMMED CRC32 = 0x2D9A260A
F100 BF – Burn File System
Note: See “B: Upgrading System Firmware” on page 145.
Use function F100 BF to burn file system when upgrading firmware, to write a file system to the flash
memory.
To write the file system to the flash, send the F100 BH command with the FTP host, file path and name,
and then enter:
F100<S>BF<CR>
XLi responds:
OK<CR><LF>
For example:
>f100 bf
OK
BURNING FILE 192-8002.fs WITH SIZE 524288
SEC: 94
SEC: 95
SEC: 96
SEC: 97
SEC: 98
SEC: 99
SEC: 100
SEC: 101
SEC: 102
FILE SYSTEM FLASH BURN COMPLETED
F100 BUFP – Burn FPGA Firmware
Note: See “B: Upgrading System Firmware” on page 145.
F100 BUFP - Burn FPGA firmware from host to target flash
Use Serial/Network port F100 BUFP when upgrading FPGA firmware - to write the FPGA program file
selected with F100 BH to the flash memory. Prior to issuing the F100 BUFP command, the host
computer must be setup as an FTP server with the new FPGA program file stored on the FTP server.
