1.6 Specifications
Introduction Table 1.1 shows the specifications for the TP9100 radios. The parameter
values quoted are minimum values. These specifications are valid for the date
of publication only. For up-to-date specifications, refer to the area on the
TaitWorld website reserved for TP9100 products.
Table 1.1 Specifications
Parameter Values
Basic characteristics
Frequency bands:
• B1 band
• H5 band
• H6 band
136 to 174MHz
400 to 470MHz
450 to 530MHz
Frequency stability ±1.5ppm
Channel capacity (simplex or semi-duplex) 512
Channel spacing:
•narrow
•medium
•wide
12.5kHz
20kHz
25kHz
Supply voltage: 7.5±1.5V DC
Antenna connector SMA
Accessory connector Ports: 1 serial, 2I/O, 1 audio tap in, 1 audio tap out, PTT,
speaker, microphone
Physical characteristics
Weight (with battery and antenna as stated, no belt
clip):
• with TPA-BA-201 (NiCd) and helical antenna
• with TPA-BA-201 (NiCd) and whip antenna
• with TPA-BA-203 (NiMH) and helical antenna
• with TPA-BA-203 (NiMH) and whip antenna
22.05oz. (625g)
21.55oz. (611g)
20.95oz. (594g)
20.46oz. (580g)
Dimensions (with battery, without antenna and
belt clip):
• height
• width
• depth
7.28in. (185mm)
2.60in. (65mm)
1.77in. (45mm)
