19 TOPA-SV-024 Test Unit
The TOPA-SV-024 test unit is used to test and maintain Tait portable and
mobile radios by providing an interface between the radio, a test PC, and
an RF communications test set.
The diagram below shows the front panel of the test unit.
19.1 Test Setup
The diagram on the following page shows how the test unit is connected to
the radio, the test PC, and the RF communications test set.
Note The test unit can also be connected to a Tait Orca portable radio
(TOP) using the TOPA-SV-007 cable, or to a T2000 radio using
the T2000-11 cable. Use with Tait Orca and T2000 radios is not
described in this section.
Figure 19.1 TOPA-SV-024 test unit
