GTS Technical Manual
technical manual swingo 855 B Power V1.00 2010.02IVZ.fm
15. March 2010 Edition: V1.00/2010
Copyright © 2010, Diversey Inc.
Index
1 Foreword
1.1 Target 2
1.2 Technical Training 2
1.3 Technical Manual 2
1.4 Conclusion 3
2 Elementary
2.1 Health & Safety 2
2.2 ESD 2
3 General
3.1 General information 2
3.1.1 Part reference 2
3.1.2 Consumable supplies 2
3.1.3 Direction description 2
3.1.4 Power source 2
3.2 Required material 3
3.2.1 Tools 3
3.2.2 Material 3
4 Technical data
4.1 Machine range 2
4.2 Technical Information 3
4.2.1 Machine profile 3
4.2.2 Technical data 3
4.2.3 Machine speed 4
4.2.4 Dimensions and weights 4
4.2.5 Battery 5
4.2.6.1 Battery compartment 5
4.2.7.2 Battery specifications 6
4.2.8 Charger 7
4.2.9 Brush system 7
4.2.10 Suction power 8
4.2.11 Additional 8
4.3 Accessories & Additional parts 9
4.3.1 Accessories 9
4.3.2 Additional parts 9
5Mechanical
5.1 Mechanical sequences 2
5.1.1 Handle/Upper part 2
5.1.2.1 Replacing of microswitch 2
5.1.3.2 Replacing of hall sensor board 3
5.1.4.3 Replacing of throttle lever 5
5.1.5.4 Replacing of vacuum motor 6
5.1.6.5 Replacing of tank cover 8
5.1.7 Squeegee lowering mechanism 11
5.1.8.1 Replacing of squeegee bracket spring 11
5.1.9 Squeegee 12
