Taski swingo 855B power - Replacing of Filter 24 V

GTS Technical Manual
15. March 2010 Edition: V1.00/2010 5-18
Copyright © 2010, Diversey Inc.
05.0 swingo 855 B Power - mechanics.fm
5.1.4.3 Replacing of filter 24V
Picture 11: Filter 24V
Remove
• Remove filter cover of filter 24V.
Ensure that no water is in the fresh water system before you
disconnect the hoses.
• Remove fixation screws from chassis.
• Thread out filter 24V from the chassis.
• Disconnect the fresh water connection.
• Disconnect the wires from coil.
• Remove complete filter 24V.
Mount
• Take new filter 24V.
• Connect wires to coil.
• Connect fresh water hoses to the filter 24V.
• Thread in the filter 24V on the chassis.
• Position fixation screws an tighten them.
• Position filter cover on the filter 24V.
