Taski swingo 855B power - System architecture

GTS Technical Manual
15. March 2010 Edition: V1.00/2010 6-2
Copyright © 2010, Diversey Inc.
06.0 swingo 855 B Power - electronics.fm
6Electrical
6.1 System architecture
6.1.1 General
• The firmware is memorised only on the power electronics.
• Applying the correct torque where required is essential for a
safe operation of the machine.
• ESD can harm the electronic boards and therefore reduce the
life time of the machine. Use always an ESD bag to protect the
electronics.
6.1.2 System overview
Picture 1: System overview
