Remarks
Based on data from the application department (Muenchwilen) the
default setting is as mentioned. Changing this setting will not bring
an improvement of the cleaning performance.
Picture 16: Default setting eccentric shaft
Picture 17: Default setting eccentric disc
• Position a new self locking nut (M6) at the eccentric disc.
• Position two new self locking nuts (M8) at the bolt, holding
brush drive unit to cradle.
• Thighten all self locking nuts.
Do not use the locking lever (07/116) to tighten the eccentric shaft
(07/110)
