GTS Technical Manual
15. March 2010 Edition: V1.00/2010 5-24
Copyright © 2010, Diversey Inc.
05.0 swingo 855 B Power - mechanics.fm
• Connect the brush motor to the power electronics.
Connect the wires of the brush motor matching the colours.
• Connect the fresh water hose to the pump.
• Connect the pump wires.
• Position the brush housing on the brush drive unit.
• Position the brush housing screws and tighten them.
• Close and lock battery compartment with the screws of the
looking system.
