6.2 Electrical sequences
6.2.1 Dashboard
Picture 3: Dashboard
6.2.1.1 Replacing of dashboard
Remove
• Remove the 5 screws of the dashboard.
• Dismount dashboard from machine.
• Disconnect all electrical connections.
Mount
• Connect electrical connections to dashboard.
• Mount dashboard on machine.
• Fix the dashboard with the 5 screws to the machine.
