Mount
• Position new belt carefully.
• Mount the small tensioning roller and push it to the limit.
• Thighten the fixation screw of the small tensioning roller.
• Position the tensioning roller on the brush base plate.
• Position the fixation screw and tighten it only as much as
required to move over the brush base plate nozzle.
• Move the tensioning roller with a 17 mm fork spanner over the
nozzle on the brush base plate.
Remarks
If you can not get over the nozzle you can adjust the small
tensioning roller slightly.
• Thighten the fixation screw of the tensioning roller completely.
• Position the cover on the brush drive unit.
• Position and tighten the fixation screws of cover.
Ensure that the belt does not touch the cover.
• Complete assembling according to the chapter REPLACING OF
BRUSH DRIVE UNIT.
