Mount
• Position the new motor/new belt.
Take care that the belt is positioned correctly.
• Insert the counter head screw.
• Position the two other screws.
Service
Apply adhesive looking on the screws (09/134).
• Tension the belt.
• Tighten all screws.
• Complete assembling according to the chapter REPLACING OF
PULLEY BELT.
• Complete assembling according to the chapter REPLACING OF
BRUSH BELT.
• Complete assembling according to the chapter REPLACING OF
BRUSH DRIVE UNIT.
