GTS Technical Manual
15. March 2010 Edition: V1.00/2010 6-8
Copyright © 2010, Diversey Inc.
06.0 swingo 855 B Power - electronics.fm
4 X9 Throttle hall sensor 2 GND
4 X9 Throttle hall sensor 3 +5V
4 X9 Throttle hall sensor 4 Microswitch (parking = open)
5 X6 Charger communication 1 Information charge - yellow
5 X6 Charger communication 2 Information charged - green
5 X6 Charger communication 3 Information charge failed - red
5 X6 Charger communication 4 Emergency loop IN (Jumper for NON BMS)
5 X6 Charger communication 5 Emergency loop OUT (Jumper for NON
BMS)
5 X6 Charger communication 6 GND
6 X5 Emergency loop 1 24V Permanent
6 X5 Emergency loop 2 Emergency loop
7B1Hall sensor 1Power hold
8 S1 Reed contact 1 Machine start
Pos. Plug Description [plug] Pin Description [pin]
Table 1: Dashboard connector description
