GTS Technical Manual
15. March 2010 Edition: V1.00/2010 6-17
Copyright © 2010, Diversey Inc.
06.0 swingo 855 B Power - electronics.fm
Pos. Plug Description [plug] Pin Description [pin]
1 B1 Battery charge (red) 1 Battery charge - Plus (+)
1 B1 Battery charge (black) 2 Battery charge - Minus (-)
2S3Power main cord 1Phase
2S3Power main cord 2Neutral
2S3Power main cord 3GND
3 X7 Charger communication 1 Not connected
3 X7 Charger communication 2 Not connected
3 X7 Charger communication 3 Emergency loop IN
3 X7 Charger communication 4 Emergency loop OUT
3 X7 Charger communication 5 GND
3 X7 Charger communication 6 Information charge failed
3 X7 Charger communication 7 Information charge
3 X7 Charger communication 8 Information charged
Table 3: Charger connector description
