32
Model PH90Operating Procedures
Step 9
Lubricate the inside of the freezer door spout, top and
bottom.
Figure 38
Step 10
Insert the draw valve from the bottom until the slot in
the draw valve comes into view.
Figure 39
Step 11
Slide the o- ring into the groove on the pivot pin and
lubricate.
Figure 40
Step 12
Install the draw handle. Slide the fork of the draw
handle in the slot of the draw valve. Secure with pivot
pin.
Figure 41
