TDK-Lambda Genesys - Page 55

49
83532002 Rev C
Safety (PE)
GND must be
connected.
10kW Platform A Output Range: 7.5V-25V
10kW/15kW Platform A & B Output Range: 30V-300V
7
6
5 4
3 8
1
10
2
7
6 5 4
3 8
1
10
2
10kW/15kW Platform C Output Range: 400V-600V
Figure 4-2: Rear Panel Connections and Switches
Safety (PE)
GND must be
connected.
Safety (PE)
GND must be
connected.
10
5
3
9
1
8
4
2
67
