TDK-Lambda Genesys - Page 92

86
83532002 Rev C
Table 8-6: Voltage Programming Range
(10kW/15kW)
Table 8-7: Current programming range (10kW)
Model
Rated Output Voltage
(VDC)
Minimum
(VDC)
Maximum
(VDC)
Model Minimum
(A)
Maximum
(A)
7.5 0.0 7.5 7.5-1000 0.0 100.0
10 0.0 10.0 10-1000 0.0 100.0
12.5 0.0 12.5 12.5-800 0.0 800.0
20 0.0 20.0 20-500 0.0 500.0
25 0.0 25.0 25-400 0.0 400.0
30 0.0 30.0 30-333 0.0 333.0
40 0.0 40.0 40-250 0.0 250.0
50 0.0 50.0 50-200 0.0 200.0
60 0.0 60.0 60-167 0.0 167.0
80 0.0 80.0 80-125 0.0 125.0
100 0.0 100.0 100-100 0.0 100.0
125 0.0 125.0 125-80 0.0 80.0
150 0.0 150.0 150-66 0.0 66.0
200 0.0 200.0 200-50 0.0 50.0
250 0.0 250.0 250-40 0.0 40.0
300 0.0 300.0 300-33 0.0 33.0
400 0.0 400.0 400-25 0.0 25.0
500 0.0 500.0 500-20 0.0 20.0
600 0.0 600.0 600-17 0.0 17.0
Table 8-8: OVP Programming Range (10kW) Table 8-9: UVL Programming Range (10kW)
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
7.5-1000 0.75 7.88 7.5-1000 0.0 7.125
10-1000 1.0 10.5 10-1000 0.0 9.5
12.5-800 1.25 13.13 12.5-800 0.0 11.875
20-500 2.0 21.0 20-500 0.0 19.0
25-400 2.5 26.25 25-400 0.0 23.75
30-333 3.0 31.5 30-333 0.0 28.5
40-250 4.0 42.0 40-250 0.0 38.0
50-200 5.0 52.5 50-200 0.0 47.5
60-167 6.0 63.0 60-167 0.0 57.0
80-125 8.0 84.0 80-125 0.0 76.0
100-100 10.0 105.0 100-100 0.0 95.0
125-80 12.5 131.25 125-80 0.0 118.75
150-66 15.0 157.5 150-66 0.0 142.5
200-50 20.0 210.0 200-50 0.0 190.0
250-40 25.0 262.5 250-40 0.0 237.5
300-33 30.0 315.0 300-33 0.0 285.0
400-25 40.0 420.0 400-25 0.0 380.0
500-20 50.0 525.0 500-20 0.0 475.0
600-17 60.0 630.0 600-17 0.0 570.0
