TDK-Lambda Genesys - Page 93

87
83532002 Rev C
Table 8-11: OVP Programming Range (15kW) Table 8-12: UVL Programming Range (15kW)
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
Model
Rated Output Voltage
(V)
Minimum
(V)
Maximum
(V)
30-500 3.0 31.5 30-500 0.0 28.5
40-375 4.0 42.0 40-375 0.0 38.0
50-300 5.0 52.5 50-300 0.0 47.5
60-250 6.0 63.0 60-250 0.0 57.0
80-187.5 8.0 84.0 80-187.5 0.0 76.0
100-150 10.0 105.0 100-150 0.0 95.0
125-120 12.5 131.25 125-20 0.0 118.75
150-100 15.0 157.5 150-100 0.0 142.5
200-75 20.0 210.0 200-75 0.0 190.0
250-60 25.0 262.5 250-60 0.0 237.5
300-50 30.0 315.0 300-50 0.0 285.0
400-37.5 40.0 420.0 400-37.5 0.0 380.0
500-30 50.0 525.0 500-30 0.0 475.0
600-25 60.0 630.0 600-25 0.0 570.0
Table 8-10: Current programming range (15kW)
Model
Minimum
(A)
Maximum
(A)
30-500 0.0 500.0
40-375 0.0 375.0
50-300 0.0 300.0
60-250 0.0 250.0
80-187.5 0.0 187.5
100-150 0.0 150.0
125-120 0.0 120.0
150-100 0.0 100.0
200-75 0.0 75.0
250-60 0.0 60.0
300-50 0.0 50.0
400-37.5 0.0 37.5
500-30 0.0 30.0
600-25 0.0 25.0
