36
4 Installation
and O
p
e
r
a
t
i
on
4.1 Installation
4.1.1 Unpacking
Remove the RBK-X1C from its packing. If there is any sign of damage, return the equipment to TE in its
original container.
Note:
The Serial Number on processor must correspond with the Serial Number on the packaging.
4.1.2 Safety
RBK-X1C must be installed in accordance with established safe working
practices. Incorrect use can cause injury.
Installation requirements must conform to local regulations.
4.1.3 Location
RBK-X1C is designed to be installed and operated in industrial environments.
However it should not be used near explosive or flammable materials or in a
location where it would be subject to moisture.
The Processor is a manually operated device and should be sited on a flat level
surface, at a height suitable for an operator - a sturdy workbench is ideal.
Take care to ensure that the ventilation fan on the back panel is not
obstructed.
4.1.4 Electrical Connections
The Processor is designed for operation from a 230V 50Hz mains supply and
is supplied with a 1.5 meters power line.
Power connections for the processor must conform to local standards and
regulations.
4.1.5 Pneumatic Connections
The Processor is designed for operation from a 4~6 bar pressure air.
Make sure air supply is available when using the Processor, not matter
activate or inactivate the Centering Device. Cut off the air supply when
operating the Processor may cause mechanical jam.
