4.2 P2P configuration
This option can only be used when the camera is already connected to the LAN or
connected to the WIFI.
Figure 4-8
4. Your Smartphone will use the WIFI connection you are currently connected to.
Insert the password of your WIFI router like seen in figure 4-5.
5. Press “Next” button.
6. System auto configure (wait). Figure 4-6
7. If failed, then click try again or repeat the above steps.
8. All configurations are saved automatically, when correct. See figure 4-7.
9. Press “Start Live preview”. See figure 4-7.
1. Press on the button and scan the QR-Code of the
device. See Figure 4-8
2. Name the device connection.
3. Username and Password are default (admin/admin).
4. Select in Live Preview between Main and Extra stream.
Default: Extra stream
Note: Under poor network environment we suggest to set to
Extra stream.
5. Press to save:
Figure 4- 5 Figure 4- 6 Figure 4- 7
