11.7.8.2 Preset
On PTZ panel, click on , select preset No., and click on to adjust this preset point.
11.7.9 Fish-eye (optional)
Enter live preview interface, select one window, click fish-eye button , and the interface
shows fish-eye effect. In the fisy-eye effect, you can slide to control the effect. Click fisy-eye
button again to exit. (Or double click to exit)
11.7.10 Bit Stream Switch
Choose between Main- and Extrastream.
1. Under live preview, select a preview window, click
on . System displays bit stream switch panel as
in Figure 11-26.
2. Switch between main and extra stream.
Click on , to switch to Fluent mode (extra
stream).
Click on , to switch to HD mode (main stream)
Click on , may customize main/extra stream. Figure 11-26
