Technaxx TX-65

34
6.6.2.3 Rule Setup
The rule setup interface is shown as in Figure 6-7.
Figure 6-7
Parameter
Function
Select
scene.
You can select the scene from the dropdown list so that you can add the
corresponding rule.
Add rule
Click it to add a rule to the selected scene.
Rule enable
Check the box here to enable the rule.
Rule name
Move you mouse to the rule name column to set a name.
Rule type
Move you mouse to the Rule type column to set the rule type. The
option includes: Tripwire, Intrusion, Abondend, Missing object detection.
Draw rule
Click button to draw current rule.
Delete rule
Click button to delete current rule.
6.6.2.3.1 Tripwire
The tripwire interface is shown as in Figure 6-88.
Figure 6-8
