Technaxx TX-65 User Manual

8
2. Device Structure
2.1 Structure Info TX-65
Refer to the following figure for cable information. See Figure 2-1.
Figure 2-1
Refer to the following sheet for detailed information.
No.
Port
Name
Function
Connection
Note
1
LAN
Network
port
Ethernet
port
Connect to standard Ethernet cable.
Note: Some devices do not support PoE.
Before making crystal head, pull the anti-dust,
waterproof cover through network cable.
2
DC
12V
Power
input port
Power port. Input DC 12V.
3
Screw
Adjust the
shield
Adjust the shield to reduce solar irradiation and
raindrop on the camera front.
