Figure 2-2
Refer to the following sheet for detailed information.
Green light slow flashing
Booting completed, await wifi config, enter smart config
status
Green light quick flashing
Wifi smart config in progress, including WPS,
management frame and etc.
Wifi connection succeeded, operate normally.
Red and green lights flash
alternately
Network connection failure or disconnection after
network connection success.
Device malfunction, fail to boot up; alarm or SD card
malfunction
