Technaxx TX-65 User Manual

22
If you want to modify the device IP address without logging in the device web interface, go
to the configuration tool main interface to set.
In the configuration tool search interface (Figure 5-1), select a device IP address and then
double click it to open the login interface. Or select an IP address and then click the Login
button to go to the login interface. See Figure 5-3.
In Figure 5-3, view device IP address, user name, password and port.
Figure 5-3
After you logged in, the configuration tool main interface is shown as below. See Figure 5-4.
Figure 5-4
Note the port information here shall
be identical with the port value you
set in TCP port in Web Network
interface. Otherwise, you cannot
login the device.
If you are using device background
upgrade port 3800 to login, other
setups are all invalid.

Technaxx TX-65 Specifications

General

Brand	Technaxx
Model	TX-65
Category	Security Camera
Language	English
