Technicolor TD5130 Setup & User Guide

15
SETUP & USER GUIDE
Copyright © 2012 Technicolor. All rights reserved.
DMS-CTC-20120508-0000 v1.0.
3 The Technicolor Wizard screen appears. Click Next to continue.
The required information on the succeeding screens
must be obtained from your Internet
Service Provider (ISP).
4 Select the DSL account service: Bridge, Routed PPP, or Routed IP. Then click Next.
If you select Routed PPP, skip to step 6.
If you select Routed IP, skip to step 7.

Technicolor TD5130 Specifications

General

Operating Temperature	0°C to 40°C
Storage Temperature	-20°C to 70°C
ADSL Standards	ANSI T1.413 Issue 2
ADSL2 Standards	ITU G.992.3 (G.dmt.bis) Annex A
ADSL2+ Standards	ITU G.992.5 Annex A
Wireless	802.11b/g
Ethernet Ports	4 x 10/100
USB Ports	1 x USB 2.0
VoIP	No
Security	WEP, WPA, WPA2
