35
RQT5941
Recording operations
Recording discs
This function makes it easier for you to record from a CD.
11 Press [w] or [q] and then [g] to set
the tape direction.
q: to record on the forward side
w: to record on the reverse side
When you select q, set the reverse mode to /. Now, if a
track is cut off at the end of the forward side, it is re-recorded
on the reverse side.
¡At the end of the reverse side, recording stops and the
current track will be interrupted.
22 Turn [INPUT SELECTOR] to select
DVD mode.
Wait for the unit to finish reading the disc.
33 Press [EDIT].
Recording starts and CD EDIT scrolls across the display.
After recording finishes
The cassette deck automatically stops.
To stop editing
Press [g] on the deck or the DVD player.
EDIT OUT is displayed and both sections stop.
Editing programmed tracks
Program the tracks (
a
steps 13, page 25) before step 3.
CD editing
1
3
1
2
REC PAUSE
3
1
2
2
3
1
2
3
A
B
3
2
3
g
1,1
g
2
11
3
1
2
22
INPUT
SELECTOR
3
1
2
33
EDIT
3
1
2
3
1
2
1 Press [w] or [q] then [g] to set the
tape direction.
q: to record on the forward side
w: to record on the reverse side
2 Press [* REC PAUSE].
The deck goes into the recording standby mode, [* REC
PAUSE] indicator lights and the play indicator starts flashing.
3 Press [q] on the DVD player.
Recording starts automatically.
Four seconds after the disc finishes, the deck goes into the
recording standby mode.
The deck may not go into recording standby mode if the disc shows
a menu after play.
To stop recording
EITHER
Press [g] on the DVD player.
The deck goes into the recording standby mode four seconds later.
OR
Press [g] on the deck.
Recording stops immediately but the disc continues to play.
To record programmed tracks
Program tracks before step 2 (
a
steps 13, page 25).
Preparation: Do the preparatory steps (
a
page 33).
Insert a disc (
a
page 16).
Normal recording
A
B

Table of Contents

Other manuals for Technics SC-HDV600

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Technics SC-HDV600 and is the answer not in the manual?

Technics SC-HDV600 Specifications

Front Speaker Specifications IconFront Speaker Specifications
impedance (high)6 Ω
impedance (low)6 Ω
input power (high, music)30 W
input power (high, DIN)15 W
input power (low, music)60 W
input power (low, DIN)30 W
output sound pressure level87 dB/W (1.0 m)
cross over frequency5 kHz
frequency range (-16 dB)48 Hz–50 kHz
frequency range (-10 dB)55 Hz–45 kHz
dimensions (W × H × D)160 × 334 × 222 mm
mass3.5 kg
Surround Speaker Specifications IconSurround Speaker Specifications
impedance8 Ω
input power (music)70 W
input power (DIN)35 W
output sound pressure level84 dB/W (1.0 m)
frequency range (-16 dB)130 Hz–20 kHz
frequency range (-10 dB)150 Hz–18 kHz
dimensions (W × H × D)140 × 99 × 118 mm
mass0.9 kg
Center Speaker Specifications IconCenter Speaker Specifications
impedance8 Ω
input power (music)160 W
input power (DIN)80 W
output sound pressure level86 dB/W (1.0 m)
cross over frequency4 kHz
frequency range (-16 dB)100 Hz–22 kHz
frequency range (-10 dB)115 Hz–20 kHz
dimensions (W × H × D)190 × 99 × 166 mm
mass1.8 kg
Tuner Specifications IconTuner Specifications
FM frequency range87.50–108.00 MHz
FM antenna terminal75 Ω (unbalanced)
AM frequency range (9 kHz step)522–1629 kHz
AM frequency range (10 kHz step)520–1630 kHz
dimensions (W × H × D)210 × 76.3 × 251 mm
mass1.1 kg
Amplifier Specifications IconAmplifier Specifications
low frequency power output (stereo mode, RMS 1 kHz)2 × 17 W
high frequency power output (stereo mode, RMS 10 kHz)2 × 8 W
low frequency power output (multichannel mode, RMS 1 kHz)2 × 10 W
low frequency power output (multichannel mode, DIN 1 kHz)2 × 8 W
high frequency power output (multichannel mode, DIN 10 kHz)2 × 6 W
high frequency power output (multichannel mode, RMS 10 kHz)2 × 8 W
surround, center power output (DIN 1 kHz)3 × 6 W
surround, center power output (RMS 1 kHz)3 × 8 W
total harmonic distortion (half power, 1 kHz)0.07%
load impedance (low frequency)6 Ω
load impedance (high frequency)6 Ω
load impedance (surround, center)8 Ω
S/N78 dB
headphones load impedance16–32 Ω
power supply (United Kingdom)AC 230–240 V, 50 Hz
power supply (others)AC 230 V, 50 Hz
power consumption110 W
standby power consumption0.9 W
dimensions (W × H × D)210 × 104.8 × 300 mm
mass3.5 kg
DVD Video Player Specifications IconDVD Video Player Specifications
signal systemPAL(PAL 60/NTSC)
output level (composite video)1 Vp-p
output level (S-Video Y)1 Vp-p
output level (S-Video C, PAL)0.3 Vp-p
output level (S-Video C, NTSC)0.286 Vp-p
pick up wavelength658/790 nm
dimensions (W × H × D)210 × 76.3 × 295 mm
mass1.5 kg
Cassette Deck Specifications IconCassette Deck Specifications
frequency response (TYPE 1)30 Hz–16 kHz
frequency response (TYPE 2)30 Hz–16 kHz
frequency response (TYPE 4)30 Hz–16 kHz
S/N (NR off)56 dB
S/N (Dolby B NR)64 dB
wow and flutter0.1% (WRMS)
dimensions (W × H × D)210 × 104.8 × 241 mm
mass1.6 kg
