6
RQT5941
Before use
The remote control
Batteries
Insert so the poles (+ and –) match those in the remote control.
Do not use rechargeable type batteries.
Do not;
¡mix old and new batteries.
¡use different types at the same time.
¡heat or expose to flame.
¡take apart.
¡short circuit.
¡attempt to recharge alkaline or manganese batteries.
Mishandling of batteries can cause electrolyte leakage which can
damage items the fluid contacts and may cause a fire.
If electrolyte leaks from the batteries, consult your dealer.
Wash thoroughly with water if electrolyte comes in contact with any
part of your body.
Remove if the remote control is not going to be used for a long
period of time. Store in a cool, dark place.
Replace if the unit does not respond to the remote control even
when held close to the front panel.
A
Use
Aim at the sensor, avoiding obstacles, at a maximum range of
7 meters directly in front of the unit.
¡Keep the transmission window and the unit’s sensor free from
dust.
¡Operation can be affected by strong light sources, such as direct
sunlight, and the glass doors on cabinets.
Do not;
¡put heavy objects on the remote control.
¡take the remote control apart.
¡spill liquids onto the remote control.
B
Type of disc for the type of
connected TV
DVDs and Video CDs are recorded using either PAL or NTSC.
Refer to this table when selecting discs.
a Clear images are shown on the screen.
b No clear images shown on the screen.
1)
If you select “NTSC” in Video – NTSC Disc Output (a page 42),
the picture may be clearer.
2)
The factory setting for NTSC disc output is PAL 60, so no changes
to the initial settings are necessary. If your television is not
equipped to handle PAL 525/60 signals the picture will not be
shown correctly.
The bottom part of the picture may be cut off if the Video CD played
does not comply with standards.
Note
TV type Disc TV monitor
Multi-
system TV
PAL
a ✓
a ✓
1)
NTSC
PAL
b ×
NTSC TV
NTSC
PAL
a ✓
PAL TV
NTSC
b ×
a ✓
2)
