Technics SC-HDV600 User Manual

Technical specifications
RQT5941-B
H0301BB0
Matsushita Electric Industrial Co., Ltd.
Osaka 542-8588, Japan
En
TUNER
■ Pre-amplifier section
Input sensitivity/impedance
EXT IN 300 mV/15 kΩ
■ Tuner section
FM frequency range 87.50–108.00 MHz
(0.05 MHz step)
FM antenna terminal 75 Ω (unbalanced)
AM frequency range
522–1629 kHz (9 kHz step)
520–1630 kHz (10 kHz step)
■ Timer section
Clock Quartz lock type
Function Play timer: everyday
Rec timer: everyday
Sleep timer: 120 min, 30 min intervals
■ General
Dimensions (W × H × D)
210 × 76.3 × 251 mm
Mass 1.1 kg
AMPLIFIER
■ Amplifier section (Stereo mode)
[Low frequency]
Power output
RMS 1 kHz, THD 10%, 6 Ω, both
channel driven 2 × 17 W
[High frequency]
Power output
RMS 10 kHz, THD 10%, 6 Ω, both
channel driven 2 × 8 W
■ Amplifier section (Multichannel mode)
[Low frequency]
Power output
DIN 1 kHz, THD 1%, 6 Ω, both
channel driven 2 × 8 W
RMS 1 kHz, THD 10%, 6 Ω, both
channel driven 2 × 10 W
Total harmonic distortion
Half power, 1 kHz, 6 Ω 0.07%
Load impedance 6 Ω
[High frequency]
Power output
DIN 10 kHz, THD 1%, 6 Ω, both
channel driven 2 × 6 W
RMS 10 kHz, THD 10%, 6 Ω, both
channel driven 2 × 8 W
Load impedance 6 Ω
[Surround, Center]
Power output
DIN 1 kHz, THD 1%, 8 Ω, both
channel driven 3 × 6 W
RMS 1 kHz, THD 10%, 8 Ω, both
channel driven 3 × 8 W
Load impedance 8 Ω
■ S/N 78 dB
Rated power, 2 V input, VGCA ON 98 dB
■ Headphones
Jack type 3.5 mm STEREO
Load impedance 16–32 Ω
■ General
Power supply
For United Kingdom
AC 230–240 V, 50 Hz
For others
AC 230 V, 50 Hz
Power consumption 110 W
STANDBY condition 0.9 W
Dimensions (W × H × D)
210 × 104.8 × 300 mm
Mass 3.5 kg
DVD VIDEO PLAYER
■ Discs played
DVD-VIDEO
VIDEO CD
CD-AUDIO (CD-DA)
CD-R/RW (CD-DA or VIDEO CD formatted
discs)
■ Video
Signal system PAL(PAL 60/NTSC)
Output level (75 Ω)
Composite video 1 Vp-p
S-Video Y 1 Vp-p
S-Video C 0.3 Vp-p (PAL)
0.286 Vp-p (NTSC)
■ Digital output terminal Optical × 1
■ Pick up wavelength 658/790 nm
(NORSK)
Bølgelengde 658/790 nm
Laser-styrke
Ingen farlig strålning sendes ut
■ General
Dimensions (W × H × D)
210 × 76.3 × 295 mm
Mass 1.5 kg
CASSETTE DECK
■ Audio section
Track system 4 track 2 channel STEREO
Frequency response (Dolby NR off)
TYPE 1 (NORMAL) 30 Hz–16 kHz (DIN)
TYPE 2 (HIGH) 30 Hz–16 kHz (DIN)
TYPE 4 (METAL) 30 Hz–16 kHz (DIN)
S/N (Signal level=max recording level,
TYPE 2)
NR off 56 dB (A weighted)
Dolby B NR 64 dB (A weighted)
■ Motor
Capstan drive DC servo motor
Reel table drive DC motor
Fast forward and rewind time (C-60)
Approx. 90 seconds
Wow and flutter 0.1% (WRMS)
■ General
Dimensions (W × H × D)
210 × 104.8 × 241 mm
Mass 1.6 kg
FRONT SPEAKER
Type 2 way, 2 speaker, bass-reflex system
Speaker(s)
Woofer: 12 cm cone type
Tweeter: 2.5 cm semi-dome type
Impedance
HIGH
∗
6 Ω
LOW
∗
6 Ω
Input power
HIGH
∗
30 W (Music), 15 W (DIN)
LOW
∗
60 W (Music), 30 W (DIN)
Output sound pressure level
87 dB/W (1.0 m)
Cross over frequency 5 kHz
Frequency range 48 Hz–50 kHz (–16 dB)
55 Hz–45 kHz (–10 dB)
■ General
Dimensions (W × H × D)
160 × 334 × 222 mm
Mass 3.5 kg
∗
HIGH stands for High Frequency.
LOW stands for Low Frequency.
SURROUND SPEAKER
(Except for United Kingdom)
Type 1 way, 1 speaker system
Closed type
Speaker(s)
Full range: 8 cm cone type
Impedance 8 Ω
Input power 70 W (Music)
35 W (DIN)
Output sound pressure level
84 dB/W (1.0 m)
Frequency range 130 Hz–20 kHz (–16 dB)
150 Hz–18 kHz (–10 dB)
■ General
Dimensions (W × H × D)
140 × 99 × 118 mm
Mass 0.9 kg
CENTER SPEAKER
(Except for United Kingdom)
Type 2 way, 3 speaker, bass-reflex system
Speaker(s)
Woofer: 8 cm cone type × 2
Tweeter: 6 cm cone type
Impedance 8 Ω
Input power 160 W (Music)
80 W (DIN)
Output sound pressure level
86 dB/W (1.0 m)
Cross over frequency 4 kHz
Frequency range 100 Hz–22 kHz (–16 dB)
115 Hz–20 kHz (–10 dB)
■ General
Dimensions (W × H × D)
190 × 99 × 166 mm
Mass 1.8 kg
Notes:
1. Specifications are subject to change
without notice.
Mass and dimensions are approximate.
2. Total harmonic distortion is measured by
the digital spectrum analyzer.

Technics SC-HDV600 Specifications

Front Speaker Specifications

impedance (high)	6 Ω
impedance (low)	6 Ω
input power (high, music)	30 W
input power (high, DIN)	15 W
input power (low, music)	60 W
input power (low, DIN)	30 W
output sound pressure level	87 dB/W (1.0 m)
cross over frequency	5 kHz
frequency range (-16 dB)	48 Hz–50 kHz
frequency range (-10 dB)	55 Hz–45 kHz
dimensions (W × H × D)	160 × 334 × 222 mm
mass	3.5 kg

Surround Speaker Specifications

impedance	8 Ω
input power (music)	70 W
input power (DIN)	35 W
output sound pressure level	84 dB/W (1.0 m)
frequency range (-16 dB)	130 Hz–20 kHz
frequency range (-10 dB)	150 Hz–18 kHz
dimensions (W × H × D)	140 × 99 × 118 mm
mass	0.9 kg

Center Speaker Specifications

impedance	8 Ω
input power (music)	160 W
input power (DIN)	80 W
output sound pressure level	86 dB/W (1.0 m)
cross over frequency	4 kHz
frequency range (-16 dB)	100 Hz–22 kHz
frequency range (-10 dB)	115 Hz–20 kHz
dimensions (W × H × D)	190 × 99 × 166 mm
mass	1.8 kg

Tuner Specifications

FM frequency range	87.50–108.00 MHz
FM antenna terminal	75 Ω (unbalanced)
AM frequency range (9 kHz step)	522–1629 kHz
AM frequency range (10 kHz step)	520–1630 kHz
dimensions (W × H × D)	210 × 76.3 × 251 mm
mass	1.1 kg

Amplifier Specifications

low frequency power output (stereo mode, RMS 1 kHz)	2 × 17 W
high frequency power output (stereo mode, RMS 10 kHz)	2 × 8 W
low frequency power output (multichannel mode, RMS 1 kHz)	2 × 10 W
low frequency power output (multichannel mode, DIN 1 kHz)	2 × 8 W
high frequency power output (multichannel mode, DIN 10 kHz)	2 × 6 W
high frequency power output (multichannel mode, RMS 10 kHz)	2 × 8 W
surround, center power output (DIN 1 kHz)	3 × 6 W
surround, center power output (RMS 1 kHz)	3 × 8 W
total harmonic distortion (half power, 1 kHz)	0.07%
load impedance (low frequency)	6 Ω
load impedance (high frequency)	6 Ω
load impedance (surround, center)	8 Ω
S/N	78 dB
headphones load impedance	16–32 Ω
power supply (United Kingdom)	AC 230–240 V, 50 Hz
power supply (others)	AC 230 V, 50 Hz
power consumption	110 W
standby power consumption	0.9 W
dimensions (W × H × D)	210 × 104.8 × 300 mm
mass	3.5 kg

DVD Video Player Specifications

signal system	PAL(PAL 60/NTSC)
output level (composite video)	1 Vp-p
output level (S-Video Y)	1 Vp-p
output level (S-Video C, PAL)	0.3 Vp-p
output level (S-Video C, NTSC)	0.286 Vp-p
pick up wavelength	658/790 nm
dimensions (W × H × D)	210 × 76.3 × 295 mm
mass	1.5 kg

Cassette Deck Specifications

frequency response (TYPE 1)	30 Hz–16 kHz
frequency response (TYPE 2)	30 Hz–16 kHz
frequency response (TYPE 4)	30 Hz–16 kHz
S/N (NR off)	56 dB
S/N (Dolby B NR)	64 dB
wow and flutter	0.1% (WRMS)
dimensions (W × H × D)	210 × 104.8 × 241 mm
mass	1.6 kg
