Technics SC-HDV600 User Manual

Equipment
connected
Recommended setting
PCM
Down
Conversion ∗
Dolby
Digital
DTS
Digital
Surround
MPEG
None
Digital (no decoder)
(MD deck, etc.)
Dolby Digital decoder
DTS Digital Surround
decoder
Dolby Digital/
DTS Digital Surround
decoder
Dolby Digital/
DTS Digital Surround/
MPEG audio decoder
No
Bitstream Off PCM
PCM
PCM
PCM
PCM
Bitstream
Bitstream
Bitstream
Bitstream
Bitstream
Off
Off
Bitstream Bitstream
PCM
PCM
Yes
Yes
Yes
Yes
Yes
47
RQT5941
Reference
Digital output settings
D
1 Go to the Audio menu.
(\ page 41–42)
2 Press the cursor buttons (e or r) to select
the item and press [ENTER].
3 Press the cursor buttons (e or r) to select
the option and press [ENTER].
Change these settings if you have connected this unit to another
piece of equipment through DIGITAL OPTICAL OUT.
Recommended digital audio output settings
Underlined items are factory preset.
∗
PCM Down Conversion
1. No (factory preset)
¡96 kHz LPCM signal are not output.
¡48 kHz signal are output as 48 kHz/16 bit signals.
¡Signals from DVDs without copyright protection may be
output as they are.
2. Yes
¡96-kHz and 48-kHz signals are output as 48-kHz/16-bit
signals when output is digital and 48-kHz signals when
output is analogue.
(This is for copyright protection.)
Caution for the digital optical output terminal:
Ensure Dolby Digital, DTS and MPEG are set to “PCM” or “Off” if
you connect this unit to a digital amplifier without a decoder. If the
signals are output as bitstream, “noise” will be output, which can
harm your ears and speakers.
Optional antenna connections
FM outdoor antenna
¡Disconnect the FM indoor antenna.
¡The antenna should be installed by a competent technician.
Note
Use outdoor antennas if radio reception is poor.
AM outdoor antenna
Run a piece of vinyl wire horizontally across a window or other
convenient location.
¡Leave the loop antenna connected.
¡Disconnect the antenna when the unit is not in use. Do not use
the antenna during an electrical storm.
Note
5-12 m
FM outdoor antenna
Tuner
75 Ω coaxial
cable
(not included)
Use the antenna
plug adapter
(included)
The United
Kingdom only
Tuner
AM outdoor antenna

Technics SC-HDV600 Specifications

Front Speaker Specifications

impedance (high)	6 Ω
impedance (low)	6 Ω
input power (high, music)	30 W
input power (high, DIN)	15 W
input power (low, music)	60 W
input power (low, DIN)	30 W
output sound pressure level	87 dB/W (1.0 m)
cross over frequency	5 kHz
frequency range (-16 dB)	48 Hz–50 kHz
frequency range (-10 dB)	55 Hz–45 kHz
dimensions (W × H × D)	160 × 334 × 222 mm
mass	3.5 kg

Surround Speaker Specifications

impedance	8 Ω
input power (music)	70 W
input power (DIN)	35 W
output sound pressure level	84 dB/W (1.0 m)
frequency range (-16 dB)	130 Hz–20 kHz
frequency range (-10 dB)	150 Hz–18 kHz
dimensions (W × H × D)	140 × 99 × 118 mm
mass	0.9 kg

Center Speaker Specifications

impedance	8 Ω
input power (music)	160 W
input power (DIN)	80 W
output sound pressure level	86 dB/W (1.0 m)
cross over frequency	4 kHz
frequency range (-16 dB)	100 Hz–22 kHz
frequency range (-10 dB)	115 Hz–20 kHz
dimensions (W × H × D)	190 × 99 × 166 mm
mass	1.8 kg

Tuner Specifications

FM frequency range	87.50–108.00 MHz
FM antenna terminal	75 Ω (unbalanced)
AM frequency range (9 kHz step)	522–1629 kHz
AM frequency range (10 kHz step)	520–1630 kHz
dimensions (W × H × D)	210 × 76.3 × 251 mm
mass	1.1 kg

Amplifier Specifications

low frequency power output (stereo mode, RMS 1 kHz)	2 × 17 W
high frequency power output (stereo mode, RMS 10 kHz)	2 × 8 W
low frequency power output (multichannel mode, RMS 1 kHz)	2 × 10 W
low frequency power output (multichannel mode, DIN 1 kHz)	2 × 8 W
high frequency power output (multichannel mode, DIN 10 kHz)	2 × 6 W
high frequency power output (multichannel mode, RMS 10 kHz)	2 × 8 W
surround, center power output (DIN 1 kHz)	3 × 6 W
surround, center power output (RMS 1 kHz)	3 × 8 W
total harmonic distortion (half power, 1 kHz)	0.07%
load impedance (low frequency)	6 Ω
load impedance (high frequency)	6 Ω
load impedance (surround, center)	8 Ω
S/N	78 dB
headphones load impedance	16–32 Ω
power supply (United Kingdom)	AC 230–240 V, 50 Hz
power supply (others)	AC 230 V, 50 Hz
power consumption	110 W
standby power consumption	0.9 W
dimensions (W × H × D)	210 × 104.8 × 300 mm
mass	3.5 kg

DVD Video Player Specifications

signal system	PAL(PAL 60/NTSC)
output level (composite video)	1 Vp-p
output level (S-Video Y)	1 Vp-p
output level (S-Video C, PAL)	0.3 Vp-p
output level (S-Video C, NTSC)	0.286 Vp-p
pick up wavelength	658/790 nm
dimensions (W × H × D)	210 × 76.3 × 295 mm
mass	1.5 kg

Cassette Deck Specifications

frequency response (TYPE 1)	30 Hz–16 kHz
frequency response (TYPE 2)	30 Hz–16 kHz
frequency response (TYPE 4)	30 Hz–16 kHz
S/N (NR off)	56 dB
S/N (Dolby B NR)	64 dB
wow and flutter	0.1% (WRMS)
dimensions (W × H × D)	210 × 104.8 × 241 mm
mass	1.6 kg
