TechnipFMC Smith Meter AccuLoad IV User Manual

AccuLoad IV Installation & Maintenance Manual
Installation 41
Figure 32: RTD Temperature Probe Analog Inputs
RTD +
SIG +
SIG -
RTD -
AccuLoad
Red
Red
Black
Black
Resistance Temperature
Probe
4
A4M TBE6
13, 14, or 15
3
1
2
Figure 33: Active 4-20 mA Analog Inputs
RTD +
SIG X +
SIG X -
RTD -
Ground (TB4)
AccuLoad IV A4M
Terminal Block TB5
4-20 mA
Transmitting Device
GND
Vin
Figure 34: Passive 4-20 mA Analog Inputs
RTD +
SIG X +
SIG X -
RTD -
Ground (TB4)
AccuLoad IV A4M
Terminal Block TB5
4-20 mA
Transmitting Device
GND
Vin
External Power
Figure 35: Analog Outputs
RTD +
SIG X +
SIG X -
RTD -
Ground (TBE4)
AccuLoad IV A4M
4-20 mA
Receiving Device
GND
Terminal Block TBE5
