ROTEX 600 XTPRO: Service & Maintenance Manual - rev. 1.1
Page 2.5
RT-5/L: Alternator cable
Alternator interface board – Alternator – Resistor
Alternator
interface board
CN2
Signal Color Alternator Resistor
1 Alternator RPM X 6 Violet Red
eyelet 4
-
2 Resistor - Blue
Blue
Yellow
eyelet 6
Yellow eyelet 4
3 Resistor + Red
Red
Yellow
eyelet 6
5 Ground Black -
Yellow
eyelet 4
4 Excitation Orange Red Faston
RT-6/L-6: Low voltage power supply cable
Power supply – Alternator interface board
Power supply
CN2 FG
Signal Color Alternator
interface board
CN3
2 + 5 Vdc Yellow 4
3 Ground Black 3
4 Faston Ground Back -
5 + 12 Vdc Red 2
XC-1: Output ports cable
CPU board – RJ45-RS232 board
CPU board
CN2
Signal Color RJ45-RS232
board
CN4
1 +12 Vdc flat 1
2 +12 Vdc flat 2
3 Tx to TGS flat 3
4 +5 Vdc flat 4
5 Rx from TGS flat 5
6 Tx to PC flat 6
7 Ground flat 7
8 Rx from PC flat 8
9 Ground flat 9
10 Ground flat 10
