ROTEX 600 XTPRO: Service & Maintenance Manual - rev. 1.1
Page 2.4
2.5.2. WIRING
RT-1A: Internal connecting cable
CPU board – Connector on frame
CPU board
CN1
Signal Color Patch cable
CN10
1 +12 Vdc Red 1
2 + 5 Vdc Orange 2
3 Ground Black 3
4 -12 Vdc Blue 4
5 Alternator RPM X 6 White 5
6 Alternator control frequency Brown 6
RT-1B: Internal connecting cable
Connector on frame – Alternator interface board
Patch cable
CN11
Signal Color Alternator
interface board
CN1
1 +12 Vdc Red 1
2 + 5 Vdc Orange 2
3 Ground Black 3
4 -12 Vdc Blue 13
5 Alternator RPM X 6 White 5
6 Alternator control frequency Brown 6
RT-3/L: High voltage power supply cable
Power input socket – Filter
Power entry Signal Color Filter
Faston Live Blue Faston
Faston Neutral Black Faston
Faston Ground Yellow-
green
Faston
RT-4/L: High voltage power supply cable
Filter – Power supply
Filter Signal Color Power supply
CN1
Faston Live Blue 4
Faston Neutral Black 6
