Technogym Rotex 600 XTPRO - Disassembling the Pedal Wheels

ROTEX 600 XTPRO: Service & Maintenance Manual - rev. 1.1
Page 7.21
7.19. DISASSEMBLING THE PEDAL WHEELS
Figure 7.19-1
Carry out the procedure described in paragraph
7.15. “Disassembling the rear cover”.
For each PEDAL WHEEL:
1. Unscrew the screw a using a 24-mm pin
wrench.
2. Remove the PEDAL WHEEL.
To reassemble the PEDAL WHEELS, carry out
the above steps in reverse order.
