Techroutes WG3100 Series User Manual

WG3100-Series GSM VoIP Gateway User Manual
_______________________________________________________________________________
Techroutes Network Pvt. Ltd.
27
Parameters
Description
Port
GSM port number
Start Date/Answer Date
start and end time of calls
Direction
IP to GSM:
outbound calls from softswitch/IPPBX to mobile network
GSM to IP:
incoming calls from mobile network to IPPBX/ Softswitch
Source
Calling number
Destination
Called number
Stauts
Answered: the call was established successful
Canceded: the call was canceled by calling party
No Carrier: the call was rejected by mobile network
Not Answered: no body to answer the call
Busy: user busy
Durations
Call duration of the call
RTP send/recv/loss rate
RTP Statistics of the call
4.4.6 Lock BCCH History
Figure 4-4-6 Auto Lock BCCH History
